Intel Desktop Board DH61AGL Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Battery
B Standby power LED
C Intel H61 Express Chipset
D Back panel connectors
E Internal power connector
F System fan header
G Single-port USB 2.0 header
H SATA 3.0 Gb/s connectors through the PCH
I SATA power connector
J Processor fan header
K BIOS Setup configuration jumper
L System ID / Custom Solutions header
M Front panel header
N Backlight off and mute header
O LVDS connector
P DDR3 SO-DIMM 2 socket
Q DDR3 SO-DIMM 1 socket
R FPD brightness connector
S Front panel dual-port USB 2.0 connector (single key)
T Front panel dual-port USB 2.0 connector (dual key)
U LGA1155 processor socket
V PCI Express Half-Mini Card connector
W DMIC header
X Internal stereo speakers connector
Y Front panel audio header
