Product Description
21
1.6 Intel
®
H67 Express Chipset
Intel H67 Express Chipset with Direct Media Interface (DMI) interconnect provides
interfaces to the processor and the USB, SATA, LPC, LAN, PCI, and PCI Express
interfaces. The Intel H67 Express Chipset is a centralized controller for the board’s I/O
paths.
For information about Refer to
The Intel H67 chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.7 Graphics Subsystem
The board supports graphics through either Intel Graphics Technology or a PCI
Express 2.0 x16 add-in graphics card.
1.7.1 Integrated Graphics
The board supports integrated graphics through the Intel
®
Flexible Display Interface
(Intel
®
FDI) for processors with Intel Graphics Technology.
NOTE
If using a processor with integrated graphics, the board will support only two of the
integrated graphics interfaces simultaneously: DisplayPort, DVI-I, DVI-D. Also, during
the Power On Self Test (POST), the board will not output to the DisplayPort if DVI-I or
DVI-D is used concurrently with DisplayPort.
1.7.1.1 Intel
®
High Definition (Intel
®
HD) Graphics
The Intel HD graphics controller features the following:
• 3D Features
⎯ DirectX10.1 and OpenGL 3.0 compliant
⎯ DirectX 11.0* CS4.0 only
⎯ Shader Model 4.0
• Video
⎯ Hi-Definition content at up to 1080p resolution
⎯ Hardware accelerated MPEG-2, VC-1/WMV and H.264/AVC Hi-Definition video
formats
⎯ Intel
®
HD Technology with Advanced Hardware Video Transcoding
⎯ Blu-ray S3D via HDMI 1.4
