Intel DH67CF Product Guide

9
1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DH67CF. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
Mini-ITX (170.18 millimeters [6.7 inches] x 170.18 millimeters
[6.7 inches])
Processor
• Intel
®
Core™ i7, Intel
®
Core™ i5, and Intel Core™ i3 processors
with up to 65 W TDP in an LGA1155 socket:
― Integrated graphics processing (processors with Intel
®
HD
Graphics 2000 and 3000)
― External graphics interface controller
― Integrated memory controller
Chipset Intel
®
H67 Express Chipset consisting of the Intel
®
H67 Express
Platform Controller Hub (PCH)
Memory
• Two 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
• Dual Channel DDR3 1333 MHz and DDR3 1066 MHz support
• Support for 1 Gb, 2 Gb, and 4 Gb memory technology
• Support for up to 16 GB of system memory with two DIMMs using
4 Gb memory technology
• Support for non-ECC memory
• Support for 1.35 V low voltage JEDEC memory
Graphics
• Integrated graphics support for processors with Intel HD 2000 or
3000 Graphics:
― High-Definition Multi-media Interface* (HDMI*)
― DisplayPort* Interface
― DVI-I
• Discrete graphics support for a PCI Express* 2.0 x16 add-in
graphics card
Audio
• 10-channel (7.1+2) Intel
®
High Definition Audio (Intel
®
HD Audio)
using a Realtek* ALC892 audio codec including:
― Front panel audio header with support for Intel HD Audio and AC
’97 Audio
― Five analog audio jacks on the back panel
― Onboard S/PDIF out header and back panel optical S/PDIF out
connector
• 8-channel (7.1) Intel HD Audio via the HDMI interface
• 8-channel (7.1) Intel HD Audio via the DisplayPort interface
Expansion
Capabilities
One PCI Express 2.0 x16 add-in card connector
continued

Intel DH67CF Specifications

General

Brand	Intel
Model	DH67CF
Category	Motherboard
Language	English
