Product Description
29
1.11.2 WiFi 802.11 Wireless
The Bluetooth/WiFi Module enables the user to connect with a variety of WiFi enabled
networks, access points and allows peer to peer connections. Driver support is
provided by Microsoft operating systems like Microsoft Vista and Microsoft Windows 7
with additional support provided by the supplied WiFi driver included on the Driver
DVD and online.
• Ralink WiFi 802.11 (RT8070)
• Range up to 300 meters
• Supports the following:
⎯ IEEE 802.11B supports up to 11 Mb/s data rate
⎯ IEEE 802.11G supports up to 54 Mb/s data rate
⎯ IEEE 802.11N supports up to 150 Mb/s data rate
• Integrated Antenna
• Operating system support (Windows XP, Windows Vista, and Windows 7 both 32 bit
and 64 bit)
For information about Refer to
Obtaining WiFi information and drivers http://msdn.microsoft.com/en-
us/library/aa362932(VS.85).aspx
http://downloadcenter.intel.com
1.12 Hardware Management Subsystem
The hardware management features enable the board to be compatible with the Wired
for Management (WfM) specification. The board has several hardware management
features, including the following:
• Fan monitoring and control
• Thermal and voltage monitoring
• Chassis intrusion detection
1.12.1 Hardware Monitoring and Fan Control
The hardware monitoring and fan control subsystem is based on the Winbond
W83677HG-I device, which supports the following:
• Processor and system ambient temperature monitoring
• Chassis fan speed monitoring
• Power monitoring of +12 V, +5 V, +3.3 V, V_SM1, V_SM2, 3.3V_Standby and
+VCCP
• SMBus interface
