Intel Desktop Board DX79SR Technical Product Specification
64
Figure 18 shows the locations of
the localized high temperature zones.
Item Description
A Processor voltage regulator area
B Processor
Figure 18. Localized High Temperature Zones
Table 29 provides maximum case temperatures for the components that are sensitive
to thermal changes. The operating temperature, current load, or operating frequency
could affect case temperatures. Maximum case temperatures are important when
considering proper airflow to cool the board.
Table 29. Thermal Considerations for Components
Component Maximum Case Temperature
Processor For processor case temperature, see processor datasheets and
processor specification updates
Intel X79 Express Chipset 104
o
C (under bias)
For information about Refer to
Processor datasheets and specification updates Section 1.3, page 16
