Intel Desktop Board DZ75ML-45K Technical Product Specification
12
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Four USB 3.0 ports:
― Two USB 3.0 ports are implemented with stacked back panel connectors
(blue)
― Two front panel USB 3.0 ports are implemented through one internal
connector (blue)
• Ten USB 2.0 ports:
― Four ports implemented with stacked back panel
― Six front panel ports are implemented through three dual-port internal
headers
• Six Serial ATA (SATA) ports:
― Two internal SATA 6.0 Gb/s interfaces through the Intel Z75 Express
Chipset with Intel
®
Rapid Storage Technology RAID support (blue)
― Four internal SATA 3.0 Gb/s interfaces through the Intel Z75 Express
Chipset with Intel Rapid Storage Technology RAID support (black)
• PS/2*-style keyboard/mouse port
Expansion
Capabilities
• One PCI Express 3.0 x16 bus add-in card connector
• One PCI Express 2.0 x16 bus add-in card connector from the PCH (x4
electrically)
• Two PCI Express 2.0 x1 bus add-in card connectors from the PCH
Note: PCI Express 3.0 is only supported by 3
rd
generation Intel Core
processor family processors
BIOS
• Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI Express* Revision 3.0
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, PS/2, and USB ports
LAN Support
Gigabit (10/100/1000 Mb/s) LAN subsystem using the Intel
®
82579V Gigabit
Ethernet Controller
Legacy I/O Control
Nuvoton W83677 I/O controller for the PS/2 port and hardware management
support
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Two fan sense inputs used to monitor fan activity
• Fan speed control
