Intel Desktop Board DZ75ML-45K Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A PCI Express x16 add-in card connector (x4 electrically)
B PCI Express x1 add-in card connector
C PCI Express x16 add-in card connector
D Battery
E PCI Express x1 add-in card connector
F Back panel connectors
G 12 V processor core voltage connector (2 x 4 pin)
H LGA1155 processor socket
I Processor fan header
J DIMM 3 (Channel A DIMM 0)
K DIMM 1 (Channel A DIMM 1)
L DIMM 4 (Channel B DIMM 0)
M DIMM 2 (Channel B DIMM 1)
N Front chassis fan header
O Chassis intrusion header
P Piezoelectric speaker
Q BIOS Setup configuration jumper block
R Main power connector (2 x 12)
S Standby power LED
T Front panel USB 3.0 connector
U SATA 6.0 Gb/s connector through the PCH (blue)
V SATA 3.0 Gb/s connector through the PCH (black)
W Front panel header
X Alternate front panel power/sleep LED header
Y Intel Z75 Express Chipset
Z Front panel USB 2.0 headers
AA Rear chassis fan header
BB S/PDIF out header
CC Front panel audio header
