63
3 Overview of BIOS Features
3.1 Introduction
The board uses a Intel Visual BIOS that is stored in the Serial Peripheral Interface
Flash Memory (SPI Flash) and can be updated using a disk-based program. The SPI
Flash contains the Visual BIOS Setup program, POST, the PCI auto-configuration
utility, LAN EEPROM information, and Plug and Play support.
The BIOS displays a message during POST identifying the type of BIOS and a revision
code. The initial production BIOSs are identified as
ML7510H.86A.
When the BIOS Setup configuration jumper is set to configure mode and the computer
is powered-up, the BIOS compares the CPU version and the microcode version in the
BIOS and reports if the two match.
The BIOS Setup program can be used to view and change the BIOS settings for the
computer. The BIOS Setup program is accessed by pressing the <F2> key after the
Power-On Self-Test (POST) memory test begins and before the operating system boot
begins. The menu bar is shown below.
NOTE
BIOS option for Text based Classic Mode configured as below.
Maintenance Main Configuration Performance Security Power Boot Exit
NOTE
The maintenance menu is displayed only when the board is in configure mode.
Section 2.3 on page 54 shows how to put the board in configure mode.
