Intel Desktop Board DZ77RE-75K Technical Product Specification
32
1.9.2 Thunderbolt™ Technology Interface
The board’s Thunderbolt Technology Interface is supported by an Intel
®
L3310L CIO
10 Gb Controller.
The Thunderbolt controller connects a PC and other devices, transmitting and receiving
information for both PCI Express and DisplayPort* protocols. The Thunderbolt
controller switches between the two protocols to support communications over a single
cable.
Thunderbolt technology is implemented on Intel Desktop Board DZ77RE-75K as a plug
and play interface. No software drivers are required.
1.10 Bluetooth*/WiFi Module
The WiFi/Bluetooth* module is supplemental hardware that is included with certain
Desktop Boards (see Figure 6).
Figure 6. Bluetooth/WiFi Module
1.10.1 Bluetooth Technology (Module)
The Bluetooth Module enables the user to connect with a variety of Bluetooth enabled
devices. Driver support is provided by Microsoft operating systems like Microsoft Vista
and Microsoft Windows 7. The Bluetooth driver stack is supplied by Microsoft but some
Bluetooth enable devices might provide additional Bluetooth features and for proper
functioning of those features, will need their own supplied drivers installed.
• CSR Bluetooth module (BC0401PC08)
• Maximum data rate 3.0 Mb/s
• Forward and backward compatibility with Bluetooth v1.1, v1.2, v2.0, and v2.1
• Integrated Antenna
• Operating system support (Windows XP, Windows Vista, and Windows 7 both 32 bit
and 64 bit)
For information about Refer to
Obtaining Bluetooth information and drivers http://msdn.microsoft.com/en-
us/library/aa362932(VS.85).aspx
