(2) COM5/COM6(9-Pin): Serial Port Header
COM Port 9
-pin Block
DCD
Pin1
Pin6
Pin5
SIN
SOUT
DTR
GND
DSR
RTS
CTS
RI
(3) TX-RXCOM6 (4-Pin): RS232/422/485 Header
TX-RXCOM6 Header
Pin 1
TXDN
RXDP
RXDN
TXDP
4
2
3
