(4) GPIO_CON(10-pin): GPIO Header
GPIO_CON Header
9
GPIO30
GND
GPIO32
GPIO34
GPIO36
GPIO31
GPIO35
GPIO33
2
Pin 1
10
GPIO37
VCC5V
(5) USB1/USB2 (9-pin): USB Port Headers
GND
VCC
+DATA
Pin 1
GND
NC
USB Port Header
-DATA
VCC
-DATA
+DATA
