16
(9) SYSFAN1 (3-pin), SYSFAN2 (4-pin), CPUFAN1 (4-pin): FAN Headers
SYS
FAN2
Pin1
FAN Headers
Control
Pin1
Control
CPUFAN
Pin1
GND
+12V Fan Power
Fan Clock
SYSFAN1
+12V Fan Power
Fan Clock
GND
GND
+12V Fan Power
Fan Clock
(10) CIR (4-Pin): CIR Header
CIR Header
GND
NC
5VSB
CIR LED-
VCC5
CIR Learn
2
Pin 1
CIR RX
