Intel NUC 8 Mainstream-G NUC8i7INH User Manual

9
NUC8i7INHX, NUC8i7INHP, NUC8i7INHZ, NUC8i5INHX, NUC8i7INHP
User Guide – April 2019
4.0 Change the M.2 SSD
Intel NUC kits NUC8i7INH and NUC8i5INH support 80mm SSDs.
Pre-installed M.2
NUC8i5INHP
256GB m.2 SSD
NUC8i7INHP
256GB m.2 SSD
NUC8i7INHZ
128GB m.2 SSD
Find compatible M.2 SSDs in the Intel Product Compatibility Tool:
• NUC8i5INH
• NUC8i7INH
To install a different M.2 SSD:
1. Remove the small silver screw from the 80mm or 42mm metal standoff on the
board (A).
2. Remove the pre-installed SSD from the connector.
3. Align the space at the bottom of the new M.2 SSD to the key on the connector.
4. Secure the card to the standoff with the small silver screw (C).
