Intel NUC7i3BNH User Manual

Intel NUC Kit NUC7i7BNH, NUC7i5BNH & NUC7i3BNH User Guide
7
Attach and Use the VESA Bracket (Optional)
Follow these instructions to attach and use the VESA mount bracket:
1. Attach the VESA bracket to the back of the monitor or TV, using the four small black screws that
were included in the box.
2. Attach the two slightly larger black screws to the bottom chassis cover of the Intel NUC.

Intel NUC7i3BNH Specifications

General

Processor	Intel Core i3-7100U
Processor Cores	2
Processor Threads	4
Processor Base Frequency	2.4 GHz
Graphics	Intel HD Graphics 620
Graphics Base Frequency	300 MHz
Graphics Max Dynamic Frequency	1.0 GHz
Max Memory Size	32 GB
Number of Memory Slots	2
Storage Interface	SATA 6.0 Gb/s
SATA Ports	1
Ethernet	10/100/1000 Mbps
Dimensions	115 x 111 x 51 mm
Operating System Support	Windows 10, Linux
Processor Cache	3 MB
Memory Type	DDR4-2133
M.2 Slot	M.2 22x42/80
USB Ports	4 x USB 3.0
HDMI Ports	1
Audio	3.5mm Headphone/Microphone Jack
Power Supply	65W external power adapter
Thunderbolt Ports	1 (USB-C Thunderbolt 3)
