Intel NUC7i3BNK User Manual

Intel NUC Kit NUC7i5BNK & NUC7i3BNK User Guide
2
Before You Begin
CAUTIONS
The procedures in this user guide assume familiarity with the general terminology associated with
personal computers and with the safety practices and regulatory compliance required for using
and modifying electronic equipment.
Disconnect the computer from its power source and from any telecommunications link or network before
performing any of the procedures described in this guide. Failure to disconnect power,
telecommunications links, or networks before you open the computer or perform any procedures can
result in personal injury or equipment damage. Some circuitry on the board can continue to operate
even though the front panel power button is off.
Follow these guidelines before you begin:
 Always follow the steps in each procedure in the correct order.
 Set up a log to record information about your computer, such as model, serial numbers,
installed options, and configuration information.
 Electrostatic discharge (ESD) can damage components. Perform the procedures described in
this chapter only at an ESD workstation using an antistatic wrist strap and a conductive foam
pad. If such a station is not available, you can provide some ESD protection by wearing an
antistatic wrist strap and attaching it to a metal part of the computer chassis.
Installation Precautions
When you install and test the Intel NUC, observe all warnings and cautions in the installation
instructions.
To avoid injury, be careful of:
 Sharp pins on connectors
 Sharp pins on circuit boards
 Rough edges and sharp corners on the chassis
 Hot components (such as SSDs, processors, voltage regulators, and heat sinks)
 Damage to wires that could cause a short circuit
Observe all warnings and cautions that instruct you to refer computer servicing to qualified
technical personnel.
Observe Safety and Regulatory Requirements
If you do not follow these instructions, you increase your safety risk and the possibility of
noncompliance with regional laws and regulations.

Intel NUC7i3BNK Specifications

General

BIOS type	EEPROM
BIOS memory size	64 Mbit
Processor socket	BGA 1356
Audio output channels	7.2 channels
Number of processors supported	1
Processor cores	2
Processor model	i3-7100U
Processor family	Intel® Core™ i3
Processor threads	4
Built-in processor	Yes
Processor codename	Kaby Lake
Processor frequency	2.4 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Thermal Design Power (TDP)	15 W
Compatible memory cards	SDXC
Storage drive interface	M.2, PCI Express, Serial ATA III
Supported storage drive types	SSD
ECC	No
Memory voltage	1.2 V
Memory channels	Dual-channel
Memory slots type	SO-DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133 MHz
Maximum graphics card memory	32768 MB
On-board graphics card model	Intel® HD Graphics 620
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
USB 2.0 ports quantity	0
ARK ID	95069
Chassis type	UCFF
Cooling type	-
Product type	Mini PC barebone
Product color	Black
LED indicators	Power
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Power supply	65 W
Power supply type	External AC adapter
AC adapter output voltage	19 V
PCI Express slots version	3.0
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Processor ARK ID	95442
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	111 mm
Width	115 mm
Height	35 mm
