Intel NUC7i5BNHXF User Manual

User Guide for NUC7i3BNHXF, NUC7i5BNHXF, NUC7i7BNHXG
4
Upgrade System Memory
The Intel NUC Kits NUC7i3BNHXF, NUC7i5BNHXF, and NUC7i7BNHXG have two 260-pin DDR4 SO-
DIMM sockets.
Pre-installed memory
NUC7i3BNHXF
One 4GB memory module
NUC7i5BNHXF
One 4GB memory module
NUC7i7BNHXG
One 8GB memory module
To upgrade memory, be sure to select memory modules that meet these requirements:
• 1.2V low voltage memory
• 2133 MHz SO-DIMMs
• Non-ECC
Find compatible memory modules in the Intel Product Compatibility Tool:
• NUC7i3BNHXF
• NUC7i5BNHXF
• NUC7i7BNHXG
NOTE
If you plan to install only one memory module, install it in the lower memory
socket.
To upgrade or add memory, follow these steps:
1. Observe the precautions in "Before You Begin" on page 2.
2. Turn off all peripheral devices connected to the computer. Turn off the computer and
disconnect the power cord.
3. Remove the computer’s bottom chassis cover.
Upgrade to different memory
a. Remove the pre-installed memory module
i. Gently spread the retaining clips at each end of the memory socket, which causes
the module to pop out of the socket (C).
ii. Holding the module by the edges, lift it away from the socket, and store it
in an anti-static package.
b. Install the new memory module
i. Align the small space at the bottom edge of the memory module with the
key in the socket.
ii. Insert the bottom edge of the module at a 45 degree angle into the socket
(A).
iii. When the module is inserted, push down on the outer edges of the
module until the retaining clips snap into place (B). Make sure the clips
are firmly in place (C).
