Setting up the Build System
Intel Atom® Processor E3900 SoC Family/Intel® Celeron®
Processor N3350/Intel® Pentium® Processor N4200/ Intel® Celeron® Processor J3355 & J3455
October 2018 Getting Started Guide
Document Number: 334828-002US Page 11
5. If the build machine is behind a corporate network with a proxy server, create the
/home/<username>/bin/gitproxy file and insert the SOCKS proxy
configuration using the following:
$ gedit /home/<username>/bin/gitproxy
#!/bin/bash
exec socat stdio SOCKS: <proxy server IP or DNS>:$1:$2
#Make gitproxy executable.
$ chmod +x /home/<username>/bin/gitproxy
6. Generate an SSH key and add the key to your GitHub* account. Go to this link
and
follow the instructions on each subsection on the webpage.
i. Checking for existing SSH Keys
ii. Generating a new SSH Key and adding it to the ssh-agent
iii. Adding a new SSH key to your GitHub account
iv. Testing your SSH connection
7. Create and add the following lines in ~/.ssh/config by using the following:
host github.com
user git
hostname ssh.github.com
identityfile ~/.ssh/id_rsa
port 443
8. If the build machine is behind a corporate environment, add the following line to
~/.ssh/config to the following:
proxycommand /bin/nc -X connect -x <proxy server IP or
DNS>:<http port number> %h %p
tcpkeepalive yes
compression yes
connectionattempts 3
9. Reboot the build system.
10. You are now ready to clone the Intel Atom® Processor E3900 SoC Family/Intel®
Celeron® Processor N3350/Intel® Pentium® Processor N4200/ Intel® Celeron®
Processor J3355 & J3455 Yocto Project*-based BSP from the GitHub repository
and build the BSP image. Refer to Table 2
, Intel Atom® Processor E3900 SoC
Family/Intel® Celeron® Processor N3350/Intel® Pentium® Processor N4200/ Intel®
Celeron® Processor J3355 & J3455 Yocto Project* BSP for more details.
§

Intel Pentium N4200 Specifications

General

Processor Name	Intel Pentium N4200
Cores	4
Threads	4
Base Frequency	1.10 GHz
Burst Frequency	2.50 GHz
TDP	6 W
Lithography	14 nm
Launch Date	Q3'16
SDP	4 W
Embedded Options Available	No
Max Memory Size	8 GB
Max # of Memory Channels	2
ECC Memory Supported	No
Processor Graphics	Intel HD Graphics 505
Graphics Base Frequency	200 MHz
Graphics Burst Frequency	750 MHz
Execution Units	18
Max Resolution (HDMI)	4096x2160@30Hz
Max Resolution (DP)	4096x2160@60Hz
DirectX Support	12
OpenGL Support	4.4
Intel Quick Sync Video	Yes
Intel InTru 3D Technology	Yes
Intel Clear Video HD Technology	Yes
Sockets Supported	FCBGA1296
CPU Configuration	1
TJUNCTION	105°C
Instruction Set	64-bit
Intel Virtualization Technology (VT-x)	Yes
Intel 64	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Thermal Monitoring Technologies	Yes
Intel AES New Instructions	Yes
Secure Key	Yes
Intel Platform Trust Technology (Intel PTT)	Yes
Cache	2 MB
Memory Types	DDR3L/LPDDR3
Instruction Set Extensions	SSE4.2
