Hardware Installation
Internal NetportExpress PRO print server
(Ethernet and Token Ring)
PC-3124
Examples of inserting NetportExpress PRO print server cards in
printers. Your printer may look different from those shown. Make sure
the printer connector on the card is fully seated into the printer slot
connector.
PC-3126
Device ID
Switches
Printer
connector
RJ-45 and DB-9
network connectors
Diagnostics
button
Token Ring
Card
Device ID
Printer
connector
RJ-45
and BNC
network
connectors
Diagnostics
button
Ethernet Card
10Base-T
BNC
10Base-T
PC-3775
