34
What does the light by the diag button mean?
r This light, which is green when lit, is located next to the diag button
on the PRO/100 device. It should be OFF for 10 Mbps systems and ON
for 100 Mbps systems.
How should switches be set?
r For Token Ring PRO print servers only
Network speed Switch 1 Switch 2
Autosense speed Up Up
Set for 4 Mbps Down Down
Set for 16 Mbps Down Up
r For Ethernet PRO and PRO/100 print servers
Doesn’t apply. Switches are reserved for future use.
Printing problems
Can’t print (start here for most problems)
r Parallel port speed may be incorrect. Parallel port speed should match
the printer speed. See the following table.
Parallel Port
Speed Type of printer using that speed
Low HP LaserJet 3* or lower, dot matrix, or inkjet
printers
Medium Default setting. HP LaserJet 4* or equivalent, most
other printers
High HP LaserJet 5si* (24 ppm) or faster printers
Software Use only if no other speed works.
To set port speed:
• In Netport Manager, click the Properties button.
• Using telnet, access the Telnet main menu and choose
Port Configuration.
• From your web browser, enter the IP address of your
NetportExpress print server and choose Properties.
r Printer is off or is offline. Make sure the printer is operational. Print a
self-test page to make sure.
r NetportExpress print server may not be configured correctly. Check
Status in Netport Manager.
