Intel PRO/1000 GT User Manual

Label Indication Meaning
LNK
On The adapter is connected to a valid link partner.
Off No link.
ACT
On Data is being transmitted or received.
Off No data activity.
not
labeled
Flashing
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet Help
for more information.
The Intel® PRO/1000 XF Server Adapter has the following indicator lights:
Label Indication Meaning
TX On The adapter is sending data.
RX On The adapter is receiving data.
LNK
On
The adapter is connected to a valid link partner and
is receiving link pulses.
Off No link.
not
labeled
Flashing
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet Help
for more information.
The Intel® PRO/1000F Server adapter has the following indicator lights:

Intel PRO/1000 GT Specifications

General

Interface	PCI
Data Rate	10/100/1000 Mbps
Connector	RJ-45
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Form Factor	Plug-in card
Device Type	Network adapter
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate	1 Gbps
Bus Type	PCI
Full Duplex	Yes
Wake-on-LAN	Yes
Ports	1 x RJ45
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Systems Supported	Windows, Linux, NetWare
Jumbo Frames	Yes, up to 9KB
