Intel PRO/1000 GT User Manual

Indicator Lights
The Intel Server and Desktop network adapters feature indicator lights on the adapter backplate that serve to
indicate activity and the status of the adapter board. The following tables define the meaning for the possible
states of the indicator lights for each adapter board.
Dual Port QSFP+ Adapters
Label Indication Meaning
ACT/LNK
Green Linked at 40 Gb
Yellow Linked at 1/10 Gb
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter XL710-Q2 has the following indicator lights:

Intel PRO/1000 GT Specifications

General

Interface	PCI
Data Rate	10/100/1000 Mbps
Connector	RJ-45
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Form Factor	Plug-in card
Device Type	Network adapter
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate	1 Gbps
Bus Type	PCI
Full Duplex	Yes
Wake-on-LAN	Yes
Ports	1 x RJ45
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Systems Supported	Windows, Linux, NetWare
Jumbo Frames	Yes, up to 9KB
