Intel PRO/1000 GT User Manual

Single Port QSFP+ Adapters
Label Indication Meaning
ACT/LNK
Green Linked at 40 Gb
Yellow Linked at 1/10 Gb
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter XL710-Q1 has the following indicator lights:
Label Indication Meaning
ACT/LNK
Green Linked at 10 Gb
Yellow Linked at 1 Gb
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter X520-Q1 has the following indicator lights:

Intel PRO/1000 GT Specifications

General

Interface	PCI
Data Rate	10/100/1000 Mbps
Connector	RJ-45
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Form Factor	Plug-in card
Device Type	Network adapter
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate	1 Gbps
Bus Type	PCI
Full Duplex	Yes
Wake-on-LAN	Yes
Ports	1 x RJ45
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Systems Supported	Windows, Linux, NetWare
Jumbo Frames	Yes, up to 9KB
