Intel PRO/1000 GT User Manual

Dual Port SFP/SFP+ Adapters
Label Indication Meaning
LNK
Green Linked at 10 Gb
Yellow Linked at 1 Gb
ACT
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter X710-2 has the following indicator lights:
Label Indication Meaning
GRN 10G
(A or B): Green
On Linked to the LAN.
Off Not linked to the LAN.
ACT/LNK
(A or B): Green
Blinking On/Off Actively transmitting or receiving data.
Off No link.
The Intel® 10 Gigabit AF DA Dual Port Server Adapter and Intel® Ethernet Server Adapter X520
series of adapters have the following indicator lights:

Intel PRO/1000 GT Specifications

General

Interface	PCI
Data Rate	10/100/1000 Mbps
Connector	RJ-45
Network Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Form Factor	Plug-in card
Device Type	Network adapter
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate	1 Gbps
Bus Type	PCI
Full Duplex	Yes
Wake-on-LAN	Yes
Ports	1 x RJ45
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Systems Supported	Windows, Linux, NetWare
Jumbo Frames	Yes, up to 9KB
