Quad Port SFP/SFP+ Adapters
Label Indication Meaning
LNK
Green Linked at 10 Gb
Yellow Linked at 1 Gb
ACT
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter X710-4 has the following indicator lights:
Label Indication Meaning
ACT/L NK
Green Linked at 10 Gb
Yellow Linked at 1 Gb
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter X520-4 has the following indicator lights:
