Dual Port SFP/SFP+ Adapters
Label Indication Meaning
LNK
Green Linked at 10 Gb
Yellow Linked at 1 Gb
ACT
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter X710-2 has the following indicator lights:
Label Indication Meaning
GRN 10G
(A or B): Green
On Linked to the LAN.
Off Not linked to the LAN.
ACT/LNK
(A or B): Green
Blinking On/Off Actively transmitting or receiving data.
Off No link.
The Intel® 10 Gigabit AF DA Dual Port Server Adapter and Intel® Ethernet Server Adapter X520
series of adapters have the following indicator lights:
