Intel PRO/1000 MT User Manual

Dual Port Fiber Adapters
Label Indication Meaning
ACT/LNK
On The adapter is connected to a valid link partner.
Blinking
Adapter is actively passing traffic.
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet Help
for more information.
Off No link.
The Intel® 10 Gigabit XF SR Dual Port Server Adapters has the following indicator lights:
Label Indication Meaning
ACT/LNK
On The adapter is connected to a valid link partner.
Blinking
Adapter is actively passing traffic.
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet
Help for more information.
Off No link.
The Intel® PRO/1000 MF, PF, and Gigabit EF Dual Port Server Adapters have the following indicator
lights for each port:
Single Port Fiber Adapters
Label Indication Meaning
The Intel® 10 Gigabit XF SR and LR Server Adapters has the following indicator lights:

Intel PRO/1000 MT Specifications

General

Product Name	Intel PRO/1000 MT
Interface	PCI
Data Transfer Rate	1 Gbps
Connector	RJ-45
Compatibility	PC
Device Type	Network adapter
Form Factor	Plug-in card
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Bus Type	PCI
Full Duplex Support	Yes
Jumbo Frames Support	Yes
Ports	1 x RJ-45
Features	Wake on LAN (WoL)
Compliant Standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Operating Systems Supported	Windows, Linux
