Intel PRO/1000 MT User Manual

Label Indication Meaning
LNK
On The adapter is connected to a valid link partner.
Off No link.
ACT
On Data is being transmitted or received.
Off No data activity.
not
labeled
Flashing
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet Help
for more information.
The Intel® PRO/1000 XF Server Adapter has the following indicator lights:
Label Indication Meaning
TX On The adapter is sending data.
RX On The adapter is receiving data.
LNK
On
The adapter is connected to a valid link partner and
is receiving link pulses.
Off No link.
not
labeled
Flashing
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet Help
for more information.
The Intel® PRO/1000F Server adapter has the following indicator lights:

Intel PRO/1000 MT Specifications

General

Product Name	Intel PRO/1000 MT
Interface	PCI
Data Transfer Rate	1 Gbps
Connector	RJ-45
Compatibility	PC
Device Type	Network adapter
Form Factor	Plug-in card
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Bus Type	PCI
Full Duplex Support	Yes
Jumbo Frames Support	Yes
Ports	1 x RJ-45
Features	Wake on LAN (WoL)
Compliant Standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Operating Systems Supported	Windows, Linux
