Intel X550-T2 User Manual

Indicator Lights
The Intel Server and Desktop network adapters feature indicator lights on the adapter backplate that serve to
indicate activity and the status of the adapter board. The following tables define the meaning for the possible
states of the indicator lights for each adapter board.
Dual Port QSFP+ Adapters
Label Indication Meaning
ACT/LNK
Green Linked at 40 Gb
Yellow Linked at 1/10 Gb
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter XL710-Q2 has the following indicator lights:

Intel X550-T2 Specifications

General

Product Type	Network Adapter
Ports	2 x 10GBase-T
Interface	PCI Express 3.0 x4
Data Transfer Rate	10 Gbps
Connector Type	RJ-45
Form Factor	Plug-in Card
Chipset	Intel X550
Connectivity Technology	Wired
Operating Temperature	0°C to 55°C
Storage Temperature	-40°C to 70°C
Cabling Type	Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 10GBase-T
Features	VLAN support, Wake on LAN (WoL), PXE support
Compliant Standards	IEEE 802.3an, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x
Jumbo Frames	9.5KB
