Label Indication Meaning
LNK
On The adapter is connected to a valid link partner.
Off No link.
ACT
On Data is being transmitted or received.
Off No data activity.
not
labeled
Flashing
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet Help
for more information.
The Intel® PRO/1000 XF Server Adapter has the following indicator lights:
Label Indication Meaning
TX On The adapter is sending data.
RX On The adapter is receiving data.
LNK
On
The adapter is connected to a valid link partner and
is receiving link pulses.
Off No link.
not
labeled
Flashing
Identity. Use the "Identify Adapter" button in Intel
PROSet to control blinking. See Intel PROSet Help
for more information.
The Intel® PRO/1000F Server adapter has the following indicator lights:
