ZT8101 User’s Guide 45
Using the Telnet Console
Main Menu
The Main Menu has these options.
• Basic Setup
— Switch Information—Display information about the switch’s hardware and firmware.
— Basic Switch Setup—Configure the switch’s IP address.
— Serial Port Settings—Configure the switch’s serial port that is used for Telnet
communication and terminal sessions.
— Port Configurations—Enable/disable individual ports and set their speed and duplex
state.
— User Accounts—Set up user accounts, change their passwords, and modify their access
rights.
— Network Management—Set up SNMP traps and community strings.
— Switch Utilities—View the history log, ping other devices, and manage firmware and
configuration files.
— Network Monitoring—View various statistics by port or protocol and to view various
routing tables.
• Advanced Setup
— Spanning Tree—Enable/disable the Spanning Tree Protocol (STP) for the switch and on
individual ports.
— Forwarding—Reduce traffic congestion on the network by configuring MAC address
aging, unicast packet forwarding, storm control, and static IP routes.
ZT8101 Switch Management Layer 3 Switch
-------------------------------------------------------------------------------
Main Menu
Basic Setup: Advanced Setup:
Switch Information Spanning Tree
Basic Switch Setup Forwarding
Serial Port Settings IP Address Filtering
Port Configurations MAC Address Priority
User Accounts Mirroring Configurations
Network Management VLAN Configurations
Switch Utilities Link Aggregation
Network Monitoring Layer 3 - IP Networking Setup
Save Changes Logout Reboot
*******************************************************************************
Function: Browse switch information.
Message:
For Help, press F1
