72 ZT8101 User’s Guide
Using the Telnet Console
To create or modify a port-based VLAN
1. From the Main Menu, select VLAN Configurations | Configure VLAN Settings and press
Enter.
2. Toggle the Action field to Add/Modify and configure these fields.
3. Highlight APPLY and press Enter.
To create or modify an 802.1Q VLAN
1. From the Main Menu, select VLAN Configurations | Configure VLAN Settings and press
Enter.
2. Using the spacebar, toggle the Action field to Add/Modify.
3. Configure these fields.
Field Description
VLAN Name
Specifies the name of the VLAN for which ports are to be configured. The
name can be up to 32 characters. Once created, a VLAN name cannot be
modified.
VLAN Type
Specifies the type of VLAN. Use the spacebar to toggle the type to Port
Based VLAN.
Membership
Specifies the status of the port. You can enter the status indicators of
individual ports directly from the keyboard or you can use the spacebar to
toggle between M and -.
• M (member)—Designates the port as a static member.
• - (non-member)—Designates the port as not being a member of the
VLAN.
Field Description
VLAN Name
Specifies the name of the VLAN for which ports are to be configured. The
name can be up to 32 characters. Once created, the name cannot be
modified.
