1. Technical specications
Hardware
Chipset (CPU) RTL8676S
Chipset wireless RTL8192ER
Flash memory 2 MB
SDRAM memory 8 MB
2 xed antennas 5 dBi
4 LAN ports (100 Mbps each)
1 WAN port (100 Mbps)
Wireless parameters
Standards IEEE 802.11b/g/n
Radio mode MiMo
Mode of operation AP Router/Wireless Repeater
Frequency of operation 2.4 GHz
Bandwidth 20.40 MHz
Transmission rate Up to 300 Mbps
Channels of operation 1-13 (Brazil)
Maximum power (EIRP) 20 dBm (100mW)
Security WEP and WPA-WPA2/PSK (TKIP/AES)
Description of LEDs
@/WAN
Green: connected to the Internet (via cable or Repeater
mode)
Red: cable connected to WAN port, but no Internet
connection
Off: no cable on WAN port and no Internet connection when
operating in Router mode, or no main network connection
when operating in Repeater mode
Flashing green: connected to the Internet and with data
trafc in PPPoE mode
WPS
On: wireless interface active
Off: wireless interface not active
Flashing: a wireless device is connecting to the router
through the WPS function. This process can last up to 2
minutes
LED ashes only once: when a connection is detected on
one of the 4 LAN ports
Power supply
Input 100-240 V to 50/60 Hz
Output 12 Vdc / 0.5 A or 12 Vdc / 0.3 A
Maximum power consumption
6 W - source 12 Vdc / 0.5 A
3.6 W - source 12 Vdc / 0.3 A
2. Accessories
» Power supply.
» Network cable.
» Installation guide.

Intelbras IWR 3000N Specifications

General

Frequency Band	2.4 GHz
Data Transfer Rate	300 Mbps
LAN Ports	4
WAN Ports	1
WAN Port Type	RJ45
LAN Port Type	RJ45
Weight	200 g
Wireless Standard	IEEE 802.11b/g/n
Security	WEP, WPA, WPA2
Operating Modes	Router, Repeater, WISP
Antenna	2 external antennas
