INSTALLING THE ANTENNA
Preparing Antenna Supporting Pole
WARNING: Ensure that cables have been run through watertight ttings to prevent
water entry into the vessel when installation is completed.
Mounting Plate
Min. 1cm(0.4”)
Max. 3cm(15”)
Support Pedestal
Appr. Ø25.4cm(10”)
Min 60cm(24”)
Max 150cm(60”)
