Intellian t130Q User Manual

63
OPERATING THE ACU
Executing Antenna Diagnosis
SETUP MODE ?
4
YES NO
1. Press the LEFT key to move cursor to YES and press the OK key to enter setup mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter ANTENNA menu.
4
+DIAGNOSTIC
3. Press the arrow keys to move cursor to DIAGNOSTIC and press the OK key to enter
DIAGNOSTIC menu.
D IA GN OS TI C FULL TEST
FULL TEST READY
4. Press the UP and DOWN arrow keys to select a full diagnosis or single diagnosis and press
the OK key to execute the selected diagnosis.
D IA GN OS TI C FULL TEST
F UL L TES T
- 5
5. A full diagnosis is completed.
D IA GN OS TI C COMMUNICATION
C OD E 101 RESULT : PASSED
6. The diagnosis result is shown.
