7. Set the current LONGITUDE.
Press the LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Press the UP and DOWN arrow keys to increase or decrease the value.
Or press the NUMBER keys to set the desired value directly.
Press the OK key to set the LONGITUDE.
8. Set the GYRO TYPE.
Determine the type of gyro compass that is used on the ship. Ensure that the Gyro
Type is set correctly. Press the UP and DOWN arrow keys to select the gyro type
and press the OK key to set the GYRO TYPE.
9. Set the BOW OFFSET
The radome should be positioned with the BOW marker aligned as close as possible to the
centerline of the ship. Small variations from actual alignment can be compensated with the
BOW OFFSET, so precise alignment is not required.
Press the LEFT and RIGHT arrow keys until the desired character is underscored
(selected). Press the UP and DOWN arrow keys to increase or decrease the value.
Or press the NUMBER keys to set the desired value directly.
Press the OK key to set the BOW OFFSET.
10. Press the BACK key to load the current setting or abort and return to the main display.
LATITUDE LONGITUDE
52.33N
4.53E
GYRO TYPE BOW OFFSET
NMEA 000
GYRO TYPE BOW OFFSET
NMEA
000
LOAD ?
4
YES NO
