Intellian t130Q User Manual

t110W/t130W – Marine Satellite Television System
54
Antenna Settings
Setting Antenna Manual Search
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter SETUP
mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter ANTENNA menu.
4
+MANUAL SEARCH +SET POL ANGLE
+SEARCH PARAM + SE T PARAMETERS
3. Press the OK key to enter MANUAL SEARCH menu.
STEP SIZE AZIMUTH ELEVATION AGC
#
0.2 # 288.7 41.0 288 Fn
4. Current IF signal level (AGC) is displayed to assist you in manually peaking EL
for best signal level. Press the NUMBER key to change the step size(Range :
0.1~9.9). Press the LEFT and RIGHT arrow keys to move azimuth by step size
(Range : 0~360). Press the UP and DOWN arrow keys to move elevation by step
size(Range : 0~90). Press the FUNCTION key to save the bow offset when the antenna
locks onto the peak level of the AGC signal.
SAVE CURRENT SAT INFO?
4
YES NO
5. If the current settings are able to lock onto the satellite, press the LEFT key to
move cursor to YES and press the OK key to save the bow offset. It will shorten the
satellite acquisition time next time. Or you can press the RIGHT key to move
cursor to NO and press the OK key to abort and return to the previous view.
