- GPS: displays and sets current antenna’s GPS.
- Heading: displays and sets current ship’s heading information.
· Heading Device: None / NMEA/ NMEA 2000/Ground Test.
The baud rate (4800/ 9600/ 19200/ 38400) must be set if NMEA is selected.
- Bow Information: displays and sets current antenna’s bow.
- Skew Information: displays current antenna’s skew and skew offset for the
selected satellites.
· Pol Sensor Calibration: calibrates the sensor (potentiometer).
- Find Antenna Angle: displays and sets the current antenna angle. Select a desired
satellite from the drop-down menu, then longitude, azimuth, elevation and skew
information are displayed.
· Find Angles & Skew Antenna GPS: Finds the current antenna angles and
skew angle in relation to the longitude (orbit position) of the antenna's
current GPS.
- Antenna Angle: displays and sets current antenna’s absolute and relative AZ
(azimuth) position, EL (elevation) position and polarization (between Linear and
Circular). You can move antenna azimuth and elevation position and LNB Pol
angle by using the arrows or inputting a value to nd the desired satellite manually.
- Go to Position: The current position (angle) of the antenna is displayed.
Push the “Go to target Position” button after keying in the desired angle to move
the antenna to target position.
