INSTALLING THE ANTENNA
Position the Radome
The radome should be positioned with the BOW marker aligned as closely as
possible to the ship’s centerline.
Recommended size of the
support pedestal
Base Panel
Min 120cm(47”)
Base Panel
Min 0.8cm(0.3”)
Max 1.2cm(0.5”)
Supporting Pole
Appr Ø25.4cm(10”)
