19" Intelligent 8-Port PDU User Manual
5
Chapter 2: Product Diagram
1 2 3 4 5 6
Key
1. Power Input Socket: IEC320 C20
2. Output Socket: IEC C13
3. Reset Key
4. Function Key: check the machine IP address
5. Display Panel: voltage, current, temperature, humidity, etc.
6. Network Port: connect LAN or WAN
