Wireless 300N PoE Access Point • Quick Install Guide English
Thank you for purchasing this Intellinet Network Solutions
™
High Power Ceiling Mount
Wireless 300N PoE Access Point, Model 525251. This quick install guide presents basic
installation steps. For operation details and specications, refer to the user manual on
the included CD or at intellinet-network.com.
CONNECTIONS
1. Remove the back panel of the access point and mount it (ceiling, wall, post, etc.)
where the cables will reach. NOTE: Placing the access point out of easy reach may
require that you use the Web management interface for the WPS and Reset functions.
2. Connect your Ethernet cable and the power adapter to the main chassis of the
access point. NOTE: Set both cables ush in the channel openings opposite the ports.
3. Twist the main chassis onto the back panel and connect the other end of the two
cables. NOTE: You can connect the access point to an IEEE802.3af PoE-compliant
source instead of an AC wall outlet.
4. Check all LEDs on the front panel. The PWR and LAN LEDs should both be on to
indicate the access point is powered and connected properly. The WLAN LED will
light when WPS mode is enabled (refer to the user manual); both the LAN and WLAN
LEDs will blink when data is transmitted.
OPERATION
1. Enter http://192.168.2.1 on your Web browser to display a login window for the Web
management interface, where all functions and settings for the access point are
congured.
2. Enter “admin” for username and “1234” for
password, then click “OK” to display the
home page of the interface. Refer to the user
manual for further instructions.




User name:
Password:
2
4
LAN WLAN PWR
Reset/WPS
3
1
