131 Eisenhower Lane North
Lombard, IL 60148
630.268.0010 / 1.800.251.2408
P/N 53-00684-200 Rev. A 071301
www.Intellitecsve.com
Intellitec
INSTALLATION & SERVICE MANUAL
TM
50 AMP Smart Energy Management System Model 900
Branch circuit wires should be routed through the remaining knock-out holes in the back of the box. The wires should be
stripped and the ground wire of each cable connected to the GROUND bar terminal strip. The white or neutral wires
should all be connected to the NEUTRAL bar terminal strip. The black, or "hot" leads of all the uncontrolled loads should
be connected to their associated breakers. Each terminal screw should be tightened to 35 in.-lb. of torque. (See the box
drawing.)
If removed during installation, the white jumper wire should be re-installed between the NEUTRAL block and J6,
terminal 5 of the EMS module labeled "NEUTRAL". (See box drawing, page 15.)
TM
NOTE: To insure proper operation of the source sensing circuitry on the 50 AMP EMS Model 900, jumper wires
must always be connected from a line 1 breaker to J6 terminal 3, and from a line 2 breaker to J6 terminal 1. These
connections must be made even though Relay 1 or Relay 2 may not be used for controlled loads.
The black wires to the controlled loads should be connected to the proper relay output screw terminals of J6 and J7
on the EMS control module. Be sure these wires are under the screw terminals and that they are tight.
The connections are as follows:
J6 Terminal Function
1 From Circuit Breaker for Relay 2 (Must be connected to a LINE 2 Breaker)
2 Output of Relay 2
3 From Circuit Breaker for Relay 1 (Must be connected to a LINE 1 Breaker)
4 Output of Relay 1
5 Neutral
J7 Terminal Function
1 Output of Relay 3
2 From Circuit Breaker for Relay 3
3 Output of Relay 4
4 From Circuit Breaker for Relay 4
NOTE: J6 and J7 terminal blocks - Will accept up to 12 GA or 14 GA copper wire ONLY.
