AUDIO OVER ETHERNET
13
AOE-N300
Specifications
Specifications
* Design and specification are subject to be changed for the improvement of product quality without pre notice.
* Signal propagation Latency CL2 Switch 1 via to audio : About 1sec/ Data: about 100ms / Contact : about 100ms.
AOE-N300
AUDIO
Maximum Input Level +20dBV
Maximum Output Level +20dBV
Frequency Response (44.1kHz Sampling, ±1dB) 100Hz~20kHz
THD (44.1kHz Sampling) Less than 0.05%
SNR (20kHz LPF, Input 0dBV, Gain Max) 80dB
Support Sampling Frequency 44.1, 48kHz
Quantization bits 24bit
Data communication
Communication type Contact, RS-232C/RS-422
Contact Input, Output Input 8Channel, Output 8Channel
Serial communication rate 2400bps~115200bps
ETHERNET (LAN) 100/1G Base-T (RJ-45)
General characteristics
Operating temperature
-10℃~+40℃
Power Source AC 220V-240V, 50/60Hz, 15W or 24VDC, 0.5A
Weight (SET) 3.02kg/6.65lb
Dimension (SET)
482(W) x 44(H) x 280(D)mm
18.97(W) x 1.73(H) x 11.02(D)in
