7
CA-6220/8220
7. REC OUT AND TAPE IN CONTROLS
These controls adjust the levels of the stereo signals to and from a connected tape deck. The REC OUT
control sets the level of the unequalized pre-fader master mix signal that is sent for recording by the tape
deck via the REC OUT jacks. The TAPE IN control adjusts the level of the playback signal that is inserted to
the master mixing bus from the TAPE IN jacks.the GEQ. The level of these signals are adjusted by the
REC OUT and TAPE IN controls.
8. REC OUT AND TAPE IN JACKS
These phone jacks are used to send stereo signals (–10dBV) to and from a connected tape deck. The
REC OUT jacks send the unequalized pre-fader signal from the master bus for recording by the tape
deck.
The TAPE IN jacks connected the playback signal from the tape deck to the master mixing bus in front of
the GEQ. The level of these signals are adjusted by the REC OUT and TAPE IN controls.
STEREO POWERED MIXER
