5
IMS-9000
MICROPHONE CONTROLLER
Rear Panel
Rear Panel
1. AUX INPUT
Allows external sound source to be connected to the system.
2. PA OUTPUT
Allows connection to an external system, for example to a Mixer Line Input or Power Amplifier Input.
3. AC INLET
AC Cord with internal fuse. Power requirement is 230V AC, 50Hz.
4. DELEGATE MICROPHONE OUTPUT CONNECTOR
D-Sub type connector which allows connection of the delegate microphones or chairman microphones to the
master unit (4m connection leads included).
321
4
250V T3.15AL
AC INPUT
230V/50Hz
www.inter-m.com
MODEL NO. IMS-9000
MICROPHONE CONTROLLER
VOLTAGE: AC 230V, 50Hz
130W
MADE IN KOREA
CAUTION; TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
AVIS; RISQUE DE
CHOC ELECTRIQUE NE PAS OUVRIR.
CAUTION
TO REDUCE THE RISK
OF FIRE REPLACE
ONLY WITH SAME
TYPE FUSE.
UTILISER UN FUSIBLE
DE RECHANG DE
MEME TYPE.
