6
IMS-9000
MICROPHONE CONTROLLER
Applications
Applications
- Controller 1 unit can be connected and used with Delegate Unit 46EA.
However please separate and connect Delegate 23EA because D-Sub connector 2EA are attached to controller.
250V T3.15AL
AC INPUT
230V/50Hz
www.inter-m.com
MODEL NO. IMS-9000
MICROPHONE CONTROLLER
VOLTAGE: AC 230V, 50Hz
130W
MADE IN KOREA
CAUTION; TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
AVI S; RISQUE DE
CHOC ELECTRIQUE NE PAS OUVRIR.
CAUTION
TO REDUCE THE RISK
OF FIRE REPLACE
ONLY WITH SAME
TYPE FUSE.
UTILISER UN FUSIBLE
DE RECHANG DE
MEME TYPE.
TO AC 230V 50Hz
TO MIXER LINE INPUT
OR POWER AMP
CHAIRMAN UNIT
DELEGATE UNIT
DELEGATE UNIT
DELEGATE UNIT
Application Models for Conference System
Application Models for Conference System
No. Model No. Description Application
1 IMS-9000 Microphone Controller Operates and Controls the system, supplies the
chairman and delegate unit’s power and extra functions.
2 IMS-9000C Chairman Microphone Used as the priority microphone the Chairman’s unit has
control over the other microphones during use.
3 IMS-9000D Delegate Microphone A basic microphone unit which can be muted by the
Chairmans microphone.
4 IMC-04 Junction Cable 9 pin D-Sub type cable used to connect the system
IMC-15 Junction Cable components together, Microphone units are supplied
IMC-20 Junction Cable with 4m cable as standard, 15m, 20m, and 30m cables
IMC-30 Junction Cable available as an extra option.
To Next Page
