Inter-m PA-2000A User Manual

PUBLIC ADDRESS AMPLIFIER
12
PA-2000A/4000A/6000A
Specifications
Specifications
PA-2000A PA-4000A PA-6000A
Rated Output (RMS) 60W 120W 240W
Frequency CH1~CH6 120Hz-10kHz
Response
Telephone In 330Hz-3.3kHz
Link In 80Hz-12kHz
Amp In 60Hz-15kHz
T.H.D CH1~CH6, Phono Less than 1%
Telephone In, Link In Less than 0.5%
Amp In Less than 0.05% Less than 0.5%
S/N CH1~CH6 more than 50dB
Phono more than 55dB
Telephone In, Link In more than 65dB
Amp In more than 95dB
Graphic Equalizer
(100Hz,330Hz, 1kHz, 3.3kHz, 10kHz)
±12dB
Input Sensitivity CH1~CH6 -70~-22dB/600Ω
/Impedance
Phono -54dB/22kΩ
Link In -20dB/15kΩ
Telephone In EC/JAPAN : -2dB(0.775V)/600Ω, USA/CANADA : -10dB(0.3V)/600Ω
Amp In 0dB/47kΩ 0dB/4700Ω
Speaker Output/Impedance 4Ω/15.5V , 4Ω/22V 4Ω/30V
8Ω/22V 8Ω/31V 8Ω/43V
83Ω/70V 42Ω/70V 21Ω/70V
165Ω/100V 83Ω/100V 41Ω/100V
Amp Out/Impedance 0dB/600Ω
Link Out/Impedance -6dB/600Ω
Operating Temperature -10˚C ~ +40˚C
Power Source 100–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 95W 120W 240W
Weight 10kg/22lb 12kg/26lb 13.5kg/29.76lb
Dimensions
420(W)x100(H)x320(D)mm 420(W)x133(H)x320(D)mm
16.5(W)x3.9(H)x12.5(D)in 16.5(W)x5.2(H)x12.5(D)in
* Specifications and design subject to change without notice.
