Inter-m PA-2100 User Manual

17
PA-2100/2200
CD CASSETTE AMPLIFIER
16
PA-2100/2200
CD CASSETTE AMPLIFIER
Specifications
Specifications
- ELECTRICAL
Rated Output (RMS).............................................................................................................PA-2100: 100W
......................................................................................................................................PA-2200: 200W
Speaker Output/Impedance
PA-2100.....................................................................................100W: 20V/4Ω, 70V/49Ω, 100V/100Ω
PA-2200.................................................................................200W: 28.3V/4Ω, 70V/24.5Ω, 100V/50Ω
Input Sensitivity/Impedance
MIC 1, 2, 3 ..............................................................................................................................-60dB/20k
AUX 1, 2..................................................................................................................................-10dB/20k
AMP IN......................................................................................................................................0 dB/10k
Frequency Range
MIC 1, 2, 3..........................................................................................................................100Hz-12kHz
AUX 1, 2 ...............................................................................................................................60Hz-15kHz
AMP IN ...............................................................................................................................150Hz-12kHz
THD Rate...................................................................................................................................Less than 1%
Signal to Noise Ratio
MIC 1, 2, 3 ......................................................................................................................Better than 60dB
AUX 1, 2..........................................................................................................................Better than 75dB
Equalizer Amplitude Range .................................................................................................................±12dB
- CD SECTION
TYPE.................................................................................................................3 CD CAPACITY MAGAZINE
Frequency Range(±3dB).............................................................................................................20Hz-20kHz
T.H.D.....................................................................................................................................Less than 0.2%
- CASSETTE DECK SECTION
TYPE ........................................................................................................Logic controlled auto-reverse stereo
Frequency Range(±3dB).............................................................................................................125Hz-8kHz
T.H.D........................................................................................................................................Less than 2%
- GENERAL
Power Source ................................................................................100–120VAC or 230–240VAC; 50/60Hz
..............................................................(Supplied AC mains transformer depends on country requirements)
Power Consumption.............................................................................................................PA-2100: 120W
......................................................................................................................................PA-2200: 230W
Weight...................................................................................................................PA-2100: 14.5kg/31.7lb
............................................................................................................................PA-2200: 18kg/39.7lb
Dimensions...................................................................440(W)x177(H)x390(D)mm/17.3(W)x7(H)x15.4(D)in
* Specifications and design subject to change without notice.
Service
Service
Procedures
Ensure the problem is not related to operator error, or system devices that are external to this unit. Information
provided in the troubleshooting portion of this manual may help with this process. Once it is certain that the
problem is related to the product contact your warranty provider as described in the warranty section of this
manual.
Schematic
A Schematic is available by contacting your warranty provider.
Parts List
A Parts List is available by contacting your warranty provider.
Variations and Options
Variations and Options
Variations
Products supplied through legitimate sources are compatible with local AC power requirements.
Options
No optional items are available for this product.
Warranty
Warranty
Warranty terms and conditions vary by country and may not be the same for all products. Terms and conditions
of warranty for a given product may be determined first by locating the appropriate country which the product
was purchased in, then by locating the product type.
To obtain specific warranty information and available service locations contact Inter-M directly(in Korea or the
USA) or the authorized Inter-M Distributor for your specific country or region.
