Page #3 background imageLoading...
Page #3 background image
1
SPECIFICATIONS
PA-648
Rated Output Power (THD 5%, 1kHz) 480W
Frequency Response (+1/-3dB) 70Hz-18kHz
T.H.D Less than 5%
High Pass Filter (400Hz) -3dB
Gain Control 0 ~ -12dB
S/N Better than 90dB
Input Sensitivity/Impedance 1V/10kΩ Balanced
Output Voltage/Impedance 4Ω/43.8V
8Ω/62V
10.2Ω/70V
20.8Ω/100V
Operating Temperature -10C ~ +40C
Power Source 100–120VAC or 220–240VAC; 50/60Hz, 24VDC
(Supplied AC mains transformer depends on country requirements)
Power Consumption(1/8 power) 600W
Weight 24kg/52.9lb
Dimensions 482(W)×132(H)×280(D)mm/19(W)x5.2(H)x11(D)in
* Specifications and design subject to change without notice.
