PA-9312/PA-9324/PA-9336 Power Amplifier
Specifications
ELECTRICAL
Rated Output (RMS)
PA-9312: 120W 4/22V; 5.2/25V;
42/70V; 83/100V
PA-9324: 240W 4/31V; 2.6/25V;
21/70V; 42/100V
PA-9336: 360W 4/38V; 8/53V;
13.6/70V; 27.8/100V
Input Sensitivity/Impedance 1V/10k
T.H.D Less than 1%
Frequency Response ( +1/-3dB) 70Hz-20kHz
S/N Better than 95dB
High Pass Filter -3dB at 400Hz
Input Level Adjustment -12dB~0dB
GENERAL
Power Source AC 110V-240V, 50/60Hz,
DC24V
Weight
PA-9312 14Kg (30.8 lbs)
PA-9324 19Kg (41.9 lbs)
PA-9336 21Kg (46.3 lbs)
Dimensions 482(W) x 132(H) x 280(D) mm
19(W) x 5.2(H) x 11(D) in.
* Specifications and design subject to change without notice for improvements.
