MIXING AMPLIFIER
12
PMU-360N/480N/600N
13. MIX OUT
T
his line-level output connects the amplifier to an external processing unit or recorder.
14. SPEAKER OUTPUT TERMINAL
※Please note that SP 1~5 terminal will be controlled by speaker selector switch of front panel.
PMU-360N 54V/8Ω 100V/28Ω 70V/14Ω
PMU-480N 62V/8Ω 100V/21Ω 70V/11Ω
PMU-600N 70V/8Ω 100V/16Ω 70V/8Ω
